SMT Lead-free wave soldering machine for insertion PCB production

FOB Reference Price:Get Latest Price
$19,000.00 - $22,800.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
Top350
Report Suspicious Activity
Overview
Quick Details
Type:
Soldering Machine
Condition:
New
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Jaguar
Rated Duty Cycle:
24 Hour Continually
Rated Capacity:
20KW
Voltage:
380/220V
Current:
Alternating Current
Dimensions:
4500*1420*1750mm
Weight:
1500KG
Certification:
CE ISO
Usage:
Soldering Components
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Warranty:
1 Year
Power:
20kw
Product name:
wave soldering machine
PCB board width:
max 300mm
PCB conveyor height:
750mm
Spray method:
SMC & ST-8 nozzle
Flux capacity:
max 6.5L
preheating length:
2000m
preheating zone quanlity:
4 zone
Solder volume:
400KG
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
vacuum packing and wooden p[acking
Port
shenzhen

SMT Lead-free wave soldering machine for PCB max width 35cm

Specifications

Top series wave soldering design si degitalized, module defined, and human-oriented, it shows superiority in function, performance, stability, reliability, safety, maintainability, operability and humanization. It can not only reduces customers’ operation cost, and also provides an effective guarantee in quality and quantity during production. It is the “Peak work” of wave soldering industry and the preferred brand for customer investment.

1. Closed Loop control with Inverter control system to keep the stability and accuracy of speed managed.



Model No.JAGUAR Top350
Number of heating zones4
Length of heating zones2000mm
Body size4500(L)*1420(W)*1750(H)
Weight1500KG
Total/running power20KW/6-8KW
Air supply0.5MPa
Preheating methodIR(standard)
Preheating power220V 5KW
Control  methodPC +PLC
Range of temp. controlRoom temperature---300ºC
Preheating timeAbout 10-15mins for setting 150ºC
Solder typeLead-free / Sn-Pb
Solder pot capacity220KG
Solder pot temperature300ºC
Solder power380V 8KW
Solder temp. control methodPID&SSR
Wave crest drive power500W 220V
Warm-up time of solderAbout 120mins for setting 250ºC
PCB  width50-350mm
Convey  speed300-1800mm/min
Convey  directionL→R (R→L optional)
Convey   angle4-7 º
Flux pressure3-5 bar
Flux capacity6.5L







Product Description

1. Automatic conveying power system and auto synchronous board feeding functions.

2.Tin stove peak uses frequency conversing speed adjustment which can independently control the wave peak height.

3.Flux sprays system using scanning spray nozzle, Japanese nozzles and rodless pneumatic cylinders and PLC control, accurate and reliable.

4. PLC is used to control the machine, to ensure the reliability and stability of the system.

5.With Remote Infrared Ceramic heating pipe preheating device, heat radiation directly to the circuit board bottom, fast heating and stimulate the full activity of flux.

6.Special alloy transportation chain claws, non-stick tin and ensures the quality of welding PCB board.

7.Tin stove adopts imported high frequency conversion motor independent control, stable performance.

8. Lead-free solder furnace with independent design, environment protection and safety, easy to clean.

9. Preheating system uses three independent temperature control so that ensure the excellent heat preservation, temperature uniformity, temperature difference no more than ±2ºC.

10.Time can be controlled, we can preset switch functions, tin stove can heat within 90 minutes.

11.Reasonable design and sensitive fault security alarm system ensure the stable performance and operators’ safety.



Our Services

1, our service tenet: fast, thoughtful and thorough
2, service goals: service quality to win the user satisfaction
3. the service efficiency: the warranty period or the warranty as equipment failure, the supplier in the receipt of the notification, the maintenance personnel in one hour to respone.
4, service principle: product warranty period of 12 months, in the guarantee period the supplier will free maintenance and replacement of quality caused by the damaged parts.
